Model: HN8145X6
Spec: GPON/XGPON 10G Dual Band 2.4G+5G4GE+1TEL+WIFI6
| Category | Parameter | Value/Description |
|---|---|---|
| Hardware | Dimensions (H×W×D) | 40mm × 185mm × 120mm |
| Weight | ~400g | |
| Power Consumption | Static: 8W / Max: 18W | |
| Operating Temperature | 0°C to 40°C | |
| Input Voltage | 100–240V AC, 50/60Hz | |
| Network Interfaces | XG-PON | 10G Down / 2.5G Up, Class N1/N2a/E1, Wavelengths: US 1260-1280nm, DS 1575-1580nm |
| Ethernet Ports | 4×GE Ports + 1×POTS (Voice) | |
| Wi-Fi | Wi-Fi 6 (2.4G: 574Mbps, 5G: 2402Mbps), 2×2 MIMO, Beamforming, 160MHz Bandwidth, WPA3 | |
| USB | USB 2.0 (FTP/SAMBA/DLNA Support) | |
| Features | Smart O&M | OMCI/Web/TR069 Management, Rogue ONT Detection, Dual-Software Backup/Rollback |
| Security & QoS | SPI Firewall, MAC/IP/URL Filtering, 802.1p Priority, SP/WRR/SP+WRR Scheduling | |
| Multicast & Home Network | IGMP/MLD Snooping, IPv6 Dual Stack, Parental Control, Wi-Fi Roaming & Optimization | |
| Environment | Operating Humidity | 5%–95% RH (Non-condensing) |
We R&D, manufacture, and sell optical communication access systems and terminal equipment. Now we’ve taken the lead in launching a number of original products in the industry, mainly including ONU/ONT, OLT, VoIP gateways, and other network access products, which are designed to meet the needs of telecom operators. We’re committed to helping broadband users worldwide enjoy an ultra-high-speed network!
